Oracle StorageTek T10000 User Manual

View or Change Configuration Settings
Menu System 4-5
nnG = max. Gigabit speed
MM - Multimode (short wave)
SR - Multimode FCoE (short range)
SM - Single Mode (long wave)
nnnm = maximum distance, meters (m) (short wave)
nn.nk = maximum distance, kilometers (k) (long wave)
■ ?G ?? appears when an SFP module is present but unreadable.
■ No SFP appears when an SFP module is not present in the port.
Procedure:
■ Press Menu or Select to advance to the next submenu.
Port A/B Physical Addressing Submenu
The operator panel window shows either Hard PA N or Hard PA Y .
Note: Manufacturing ships drives with the Hard PA N option
selected.
Defaults to the last saved selection.
Hard PA N disables hard physical address (PA) and causes the drive to seek a soft PA
assignment at loop initialization.
Hard PA Y enables a hard PA, manually set by the Hard Physical Address Submenu. If
the preset hard PA is not available at loop initialization, the drive then seeks a soft PA.
Procedure:
■ Press Menu (No) to bypass or press Select (Yes) to enter submenus.
Port A/B Hard Physical Address Submenu
Appears only with Hard PA Y .
Note: The SL3000 and SL8500 libraries do not support AL_PA
addressing.
Defaults to the last saved selection.
The operator panel window shows PA=xx,ddd .
■ xx (hexadecimal) is the Arbitrated Loop Physical Address (AL_PA).
■ ddd is the decimal index into the ALPA table.
As you manually change the decimal index digits (valid indexes are 125 [highest
priority] through 000 [lowest priority]), the PA xx display automatically changes.
Procedure:
1. Do one of the following actions:
■ Press Menu to bypass.
■ Press Select to start the change mode.
2. Press Select to increment the digit until the desired value appears, then press
Menu to set.
