Polycom SoundStructure C16 User Manual

Design Guide for the Polycom SoundStructure C16, C12, C8, and SR12
A - 42
Examples
matrix_pan Matrix Crosspoint Pan
Description
The matrix_pan parameter is available at crosspoints where mono virtual chan-
nels are mixed to stereo virtual channels. The matrix_pan parameter provides
a way to control the amount of gain going to the left and right channels.
Examples
Command Response Description
set matrix_mute "Table
Mic 1" "Phone Out" 1
val matrix_mute "Table
Mic 1" "Phone Out" 1
Mutes the crosspoint from input "Table Mic 1" to the
output "Phone Out" so "Table Mic 1" will not be heard by
the remote participants on "Phone Out".
get matrix_mute "Table
Mic 1" "Phone Out"
val matrix_mute "Table
Mic 1" "Phone Out" 1
Queries the mute status of the crosspoint from "Table Mic
1" to the output channel apos;Phone Out".
Argument Argument value
Channel Type Matrix
Value Type Floating-Point
Read/Write Mode Read/Write
Row Phys Chans
Conferencing Mic/Line Input, Sound Reinforcement Mic/Line
Input, Analog Telephony Input, Signal Generator, Submix,
ConferenceLink Aux Input, ConferenceLink Raw Input
Row Virt Chans Mono
Col Phys Chans Conferencing Line Output, Sound Reinforcement Line
Output, Submix, ConferenceLink Aux Output
Col Virt Chans Stereo
System Limits Minimum: -1.0, Maximum: 1.0, Resolution: 0.01
Default 0.0
User Limits
Supported
No
Event Source No
Command Response Description
set matrix_pan "Phone In"
"Amplifier" 1
val matrix_pan "Phone In"
"Amplifier" 1.000
Sends the mono virtual channel "Phone In" to only the
right channel of the stereo virtual channel "Amplifier".
