QSC LA108 User Manual

10
LA108 Features
—Figure1—
Left Side
Rear
Right SideFront
Bottom
7
9
10
6
5
3
24
8
1
1. ABS enclosure
2. Steel grille
3. Front power LED
4. Handles
5. Rear panel with amplifier module, connectors and rear user interface
6. M10 pull back point
7. Dual-angle, 35 mm pole socket (0° or -7.5°)
8. Side rigging panel
9. Slip-resistant feet
10. IR sensor windows

QSC LA108 Specifications

General

Amplifier Power	N/A (passive)
Frequency Response	65 Hz – 20 kHz
Configuration	Passive
Enclosure Material	Birch plywood
Power Handling	1600 W (Peak)
Impedance	16 ohms
