48
DSP Features
Line Thru
Line In
Gain
Signal
DSPA/D
HF
Amp
LF
Amp
Limit
Analog
Network
+24 dBu
+4 dBu
Sensitivity
—Figure77—
L Class Accessories
Transportation
Both the LA108 and LA112 are designed to be highly mobile. Heavy-duty Cordura Tote accessories are available for each model.
LA108-TOTE
Heavy-duty Cordura Transport Tote with Velcro flap
LA112-TOTE
Heavy-duty Cordura Transport Tote with Velcro flap
Interconnect Jumpers
NOTE: The jumper kits below do not include short analog XLR cables, as these are readily available.
Between Loudspeakers
Both the LA108 and LA112 use the same interconnecting jumper cables for AC power and networking. When creating arrays of two or
more boxes, the LA-KIT-J jumper kit is required (depending on home country):
LA-KIT-J
International Jumper Kit (includes 2x 60 cm EtherCON jumpers / 2x 60 cm PowerCON TRUE1 jumpers with
1.5 mm
2
/H05VV cables)
LA-KIT-J-NA
North-America Jumper Kit (includes 2x 24-in EtherCON jumpers / 2x 24-in PowerCON TRUE1 jumpers with
12 AWG/SVT cables, NEC compliant)
• If there are two (2) boxes on either side of the stage, one (1) jumper kit is required.
• If there are three (3) boxes on either side of the stage, two (2) jumper kits are required.
