QSC LA108 User Manual

16
Ground Deployment
Pole Mounted on a Tripod Stand
Both LA108/LA112 active line array loudspeakers feature dual 35 mm pole sockets to accommodate either 0° or -7.5° downward tilt
of the enclosure to optimize audience coverage wherever deployed.
WARNING!: Due to the large selection of various types of tripod stands available in the market, QSC cannot
recommend a maximum deployment height. Assessment of the safety of each individual deployment is left to the user.
However, any tripod stands used must be properly rated for the deployment.
WARNING!: When deploying loudspeakers on poles, additional attention should be given to account for environmental
conditions such as level surfaces, level materials, vibrations, wind, etc, to deploy the loudspeakers in a stable and safe
manner. Use additional measures to secure the loudspeaker pole (not included) when necessary.
LA108 Loudspeaker
Up to three (3) LA108 loudspeakers may be mounted on a 45 kg (100 lb)
ratedtripod loudspeaker stand.
LA112 Loudspeaker
Up to two (2) LA112 loudspeakers may be mounted on a 45 kg (100 lb)
ratedtripod loudspeaker stand.
Pole Mounting a Loudspeaker to a Tripod
To deploy a pole mount with a tilt of 0° or -7.5°, mount the loudspeaker on a 45 kg
(100 lb) rated tripod loudspeaker stand using the 35 mm pole socket labeled 0° or
-7.5° on the bottom of the loudspeaker.
—Figure10—
LA108
LA108
LA108
LA112
LA112
—Figure11—
Pole Sockets

QSC LA108 Specifications

General

Amplifier Power	N/A (passive)
Frequency Response	65 Hz – 20 kHz
Configuration	Passive
Enclosure Material	Birch plywood
Power Handling	1600 W (Peak)
Impedance	16 ohms
