Ricoh Aficio SP C811DN Hardware Guide

2. Press the [ ] or [ ] key to select [Paper Input], and then press the [OK] key.
3. Press the [ ] or [ ] key to select [Paper Type: Tray 3,] and then press the [OK] key.
4. Press the [ ] or [ ] key to select the paper type that is loaded, and then press the [OK] key.
About two seconds later, the display returns to the Paper Input screen.
5. Press the [Online] key.
The display returns to the initial screen.
• Duplex printing is not supported for the following paper types:
• Cardstock, Thick Paper 2, Thin Paper, Thick1: Dup.Back, Thick2: Dup.Back, Coated Paper
Loading Paper in the Bypass Tray
This section explains how to load paper into the bypass tray and change paper size.
Loading standard size paper
• Shuffle paper before loading the stack onto the tray, so multiple sheets are not fed in together.
• Set the size and direction of the loaded paper on the control panel or with the printer driver. Make
sure the settings do not conflict. Otherwise, the paper may jam or the print quality may be affected.
• Load paper with the print side down and in the short-edge feed direction.
Loading Paper
107
5
