Ricoh Aficio SP C811DN Hardware Guide

Display Panel
This section explains configuration using the initial screen of the display panel.
The items are highlighted when selected.
• Do not touch the display panel.
The following screen appears when you turn on the printer.
AQC060S
1. Operational Status or Messages
Displays the printer status or the messages.
2. [Option]
Press to display the status of options installed in the printer.
3. [Prt.Jobs]
Press to display print jobs sent from a computer.
4. [Supplies]
Press to display the menu of supplies for the printer.
• Toner levels are displayed by default. To turn off the toner level display, select [Maintenance]
[General Settings] [Display Supply Info] [Off].
• Adjust the brightness if the screen is dark.
Display Panel
19
1
