Ricoh Aficio SP C811DN Hardware Guide

Adjusting Printing Position
You can adjust the printing position registrated for each tray. Only the horizontal printing position can be
adjusted. "Horizontal" means perpendicular to the feed direction. Normally you do not need to update the
printing position. However, updating is useful in some cases when the optional paper feed unit is installed.
1. Press the [Menu] key.
ATU050S
2. Press the [ ] or [ ] key to select [Maintenance], and then press the [OK] key.
3. Press the [ ] or [ ] key to select [Color Registration], and then press the [OK] key.
4. Press the [ ] or [ ] key to select [Print Test Sheet], and then press the [OK] key.
5. Press the [ ] or [ ] key to select the tray you want to adjust, and then press the [OK] key.
Adjusting Printing Position
167
8
