Attaching the SDRAM Module
• Do not touch the inside of the controller board compartment. It may cause a machine malfunction or
a burn.
• Before touching the SDRAM module, ground yourself by touching something metal to discharge any
static electricity. Static electricity can damage the SDRAM module.
• Do not subject the memory unit to physical shocks.
• The printer comes equipped with 256 MB of memory. This can be expanded to a maximum of 512
MB.
• Before using the new memory unit, you must configure settings in the printer driver.
1. Turn the printer off and unplug the power cable.
2. Remove the five screws securing the controller board.
The removed screws will be used to secure the controller board again later.
3. Holding the handle, carefully pull out the controller board.
Attaching the SDRAM Module
35
