Installing the IEEE 802.11b Interface Unit
• Before beginning work, ground yourself by touching something metal to discharge any static elec-
tricity. Static electricity can damage the unit.
• Do not subject the unit to physical shocks.
1. Check the contents of the package.
2. Turn the printer off and unplug the power cable.
3. Loosen the two screws and remove the slot cover.
The removed cover will not be reused.
2. Installing Options
46
