Replacing the Transfer Roller
1. The transfer roller is installed as shown below.
ATU052S
2. Holding the green grips on both sides, pull up the transfer roller.
ATU053S
3. Holding the green grips, pull out the transfer roller from the printer.
ATU054S
6. Replacing Consumables
140
6
