Exterior Covers (MP 501/601)
D255/D256/M281/M282 4-30 SM
4.6.8 LEFT REAR COVER
1. Open the rear upper cover [A].
2. Remove the left rear cover [A] by rotating it in the direction of the arrow. (hook×2)
 Be careful not to damage the hooks on the inside of the left rear cover when you
remove or install the left rear cover.
To Next Page
