Dedicated Transmission Parameters
D255/D256 FAX OPTION 128 SM
4.8 DEDICATED TRANSMISSION PARAMETERS
There are two sets of transmission parameters: Fax and E-mail
Each Quick Dial Key and Speed Dial Code has eight bytes of programmable parameters allocated
to it. If transmissions to a particular machine often experience problems, store that terminal's fax
number as a Quick Dial or Speed Dial, and adjust the parameters allocated to that number.
The programming procedure will be explained first. Then, the eight bytes will be described.
4.8.1 PROGRAMMING PROCEDURE
1. Set the bit 0 of System Bit Switch 00 to 1.
2. Press the [Address Book Management] icon in the home screen.
3. Select the address book that you want to program.
4. For the fax parameter, select [Fax Dest.], for the E-mail parameter, select [Email], then press
[Start].
5. The settings for the switch 00 are now displayed. Press the bit number that you wish to
change.
 To scroll through the parameter switches, press [Next] or [Previous].
6. After the setting is changed, press [OK].
7. After finishing, reset bit 0 of System Bit Switch 00 to 0.
4.8.2 PARAMETERS
Fax Parameters
The initial settings of the following fax parameters are all FF (H) - all the parameters are disabled.
Switch 00
FUNCTION AND COMMENTS
ITU-T T1 time (for PSTN G3 mode)
If the connection time to a particular terminal is longer than the NCU parameter setting,
adjust this byte. The T1 time is the value stored in this byte (in hex code), multiplied by 1
second.
Range:
0 to 120 s (00h to 78h)
FFh - The local NCU parameter factory setting is used.
Do not program a value between 79h and FEh.
To Next Page
