Ricoh IM 5000 Series User Manual

Installing the Printer Driver for Network
Connection (Windows)
When the machine and the computer are connected to the same network, the installer searches for the
machine to install the printer driver. If the installer cannot find the machine, specify the IP address or
machine name to install the printer driver.
• Manage Printers permission is required to install the driver. Log on as an Administrators group
member.
• If the "User Account Control" dialog box appears during the driver installation procedure, click
[Yes] or [Continue].
• If the "Windows Security" dialog box appears during the driver installation procedure, click [Install
this driver software anyway].
Installing the PCL 6 Printer Driver from the CD-ROM
1. Set the CD-ROM in the computer.
If the installer does not start automatically, double-click [Setup.exe] in the Windows folder of the
CD-ROM.
2. Select a language, and then click [OK].
3. Click [Recommended Install from Disk].
D0CHDA6202
4. Click [Network Printer(s)].
Installing the Printer Driver for Network Connection (Windows)
113

Ricoh IM 5000 Series Specifications

General

Bypass Tray	100 sheets
Print Speed (Black)	50 ppm
Print Resolution	1, 200 x 1, 200 dpi
Maximum Paper Size	A3
Memory (RAM)	2 GB
Compatible Models	IM 5000, IM 6000
Type	Multifunction Printer
Function	Print, Copy, Scan, Fax
Paper Tray Capacity	500 sheets
Maximum Paper Capacity	4, 700 sheets
Finisher Options	Booklet Finisher
Additional Paper Trays	Available (optional)
Duplex Printing	Yes
Connectivity	USB, Ethernet, Wi-Fi
Mobile Printing	Mopria
Control Panel	10.1-inch Smart Operation Panel
Hard Disk Drive	320 GB
Power Consumption	1, 500 W (max)
