Ricoh IM 5000 Series User Manual

10. If necessary, press the [User Management / Others] tab and specify the settings.
DZC131
11. Press [OK].
12. Press [Home] ( ) after specifying the settings.
• The connection test may take time.
• Even if the connection test was successful, the machine may fail to transfer the file if you do not
have write privileges for the file or there is not enough free hard disk space.
• If the client computer has a fixed IP address assigned to it, you can specify the IP address manually
by including it in the path name of the destination folder. For example, if the IP address is
"192.168.1.191" and the shared folder name is "user", enter "\\192.168.1.191\user" as the
path.
• When the specified destination is updated using the Central Management function, the spooled
documents are sent to the destination after updating.
Basic Procedure for Performing Send to Folder
1. Press [Scanner] on the Home screen.
2. Select [To Folder] on the scanner screen.
D0CZPM6709
Scanning Documents and Sending the Scanned Data to a Folder
163

Ricoh IM 5000 Series Specifications

General

Bypass Tray	100 sheets
Print Speed (Black)	50 ppm
Print Resolution	1, 200 x 1, 200 dpi
Maximum Paper Size	A3
Memory (RAM)	2 GB
Compatible Models	IM 5000, IM 6000
Type	Multifunction Printer
Function	Print, Copy, Scan, Fax
Paper Tray Capacity	500 sheets
Maximum Paper Capacity	4, 700 sheets
Finisher Options	Booklet Finisher
Additional Paper Trays	Available (optional)
Duplex Printing	Yes
Connectivity	USB, Ethernet, Wi-Fi
Mobile Printing	Mopria
Control Panel	10.1-inch Smart Operation Panel
Hard Disk Drive	320 GB
Power Consumption	1, 500 W (max)
