Ricoh IM 5000 Series User Manual

Web Image Monitor Screen
D0CHAA8031
1
2
3
4
1. Menu
Menu items described below are displayed.
• Status/Information: Displays the machine status, option configuration, counter, and job status.
• Device Management: Manages the machine settings and Address Book.
• Print Job/Stored File: Operates the files stored in the printer driver or document server.
• Convenient Links: Displays the link to the Favorite URL.
2. Header
An icon to link to the Login screen is placed at the top right on the screen. The Help, Version Information, and
Keyword Search buttons are also displayed.
3. Refresh/Help
(Refresh): Update the information in the work area.
(Help): View or download Help file contents.
4. Main Area
The machine status and settings are displayed.
Specifying Web Image Monitor Help
Web Image Monitor has Help to describe the function of setting items. When you use Help for the first
time, you can select to read online Help or to download Help File.
View Online Help Now
You can view the latest Web Image Monitor Help on the Internet.
Download Help File
You can download Web Image Monitor Help to the computer and view it. When you store the
downloaded Help file in the Web server and assign to the Help button ( ), you can view the
Help without connecting to the Internet.
8. Web Image Monitor
180

Ricoh IM 5000 Series Specifications

General

Bypass Tray	100 sheets
Print Speed (Black)	50 ppm
Print Resolution	1, 200 x 1, 200 dpi
Maximum Paper Size	A3
Memory (RAM)	2 GB
Compatible Models	IM 5000, IM 6000
Type	Multifunction Printer
Function	Print, Copy, Scan, Fax
Paper Tray Capacity	500 sheets
Maximum Paper Capacity	4, 700 sheets
Finisher Options	Booklet Finisher
Additional Paper Trays	Available (optional)
Duplex Printing	Yes
Connectivity	USB, Ethernet, Wi-Fi
Mobile Printing	Mopria
Control Panel	10.1-inch Smart Operation Panel
Hard Disk Drive	320 GB
Power Consumption	1, 500 W (max)
