Ricoh IM 5000 Series User Manual

7. Select [Standard TCP/IP Port] on [Create a new port:], and then click [Next].
8. Enter the IP address of this machine in [Host Name or IP address].
9. Clear the [Query the printer and automatically select the driver to use] check box, and
then click [Next].
Searching for the TCP/IP port starts.
10. When the "Additional port information required" screen is displayed, select [RICOH
Network Printer C model], and then click [Next].
11. Click [Have Disk...]
[Browse...] to specify the driver (INF file), and then click [OK].
The driver is stored in the [DISK1] folder in the folder that was created when unzipping the
downloaded file.
12. Select a printer driver to install, and then click [Next].
13. Enter the printer name as necessary, and then click [Next].
Printer driver installation starts.
14. Specify the printer as a shared printer as necessary, and then click [Next] [Finish].
If the Machine Cannot Be Found
The "Network Connection Error" screen is displayed.
Confirm and perform to , and then click [OK]. If the machine still cannot be found, specify the IP
address or machine name to install the printer driver.
5. Print
118

Ricoh IM 5000 Series Specifications

General

Bypass Tray	100 sheets
Print Speed (Black)	50 ppm
Print Resolution	1, 200 x 1, 200 dpi
Maximum Paper Size	A3
Memory (RAM)	2 GB
Compatible Models	IM 5000, IM 6000
Type	Multifunction Printer
Function	Print, Copy, Scan, Fax
Paper Tray Capacity	500 sheets
Maximum Paper Capacity	4, 700 sheets
Finisher Options	Booklet Finisher
Additional Paper Trays	Available (optional)
Duplex Printing	Yes
Connectivity	USB, Ethernet, Wi-Fi
Mobile Printing	Mopria
Control Panel	10.1-inch Smart Operation Panel
Hard Disk Drive	320 GB
Power Consumption	1, 500 W (max)
