Ricoh IM 5000 Series User Manual

• If a paper tray is pushed vigorously when putting it back into place, the position of the tray's side
fences may slip out of place.
• When loading a low number of sheets, be sure not to squeeze the side fences in too tightly. If the
side fences are squeezed too tightly against the paper, the edges may crease, thin paper may
wrinkle, or the paper may misfeed.
• You may hear the sound of rubbing paper. This is not a malfunction.
• Do not stack paper over the limit mark.
Loading Paper into Tray 1 to 4
Adjust the side and end fences according to the paper size. When loading B4 JIS, A3, or 11 × 17
paper to tray 2-4, also change the position of the auxiliary side fence.
• Do not stack paper over the limit mark. If you load paper over the limit mark, the printed images
may become slanted or a paper jam may occur.
Paper
Envelope
DZX185
Load paper into every tray in the same way. In the following example procedure, Tray 2 is used.
1. Check that paper in the paper tray is not being used, and then pull the tray out carefully.
D0CHIA5707
2. Remove paper if loaded.
9. Adding Paper and Toner
184

Ricoh IM 5000 Series Specifications

General

Bypass Tray	100 sheets
Print Speed (Black)	50 ppm
Print Resolution	1, 200 x 1, 200 dpi
Maximum Paper Size	A3
Memory (RAM)	2 GB
Compatible Models	IM 5000, IM 6000
Type	Multifunction Printer
Function	Print, Copy, Scan, Fax
Paper Tray Capacity	500 sheets
Maximum Paper Capacity	4, 700 sheets
Finisher Options	Booklet Finisher
Additional Paper Trays	Available (optional)
Duplex Printing	Yes
Connectivity	USB, Ethernet, Wi-Fi
Mobile Printing	Mopria
Control Panel	10.1-inch Smart Operation Panel
Hard Disk Drive	320 GB
Power Consumption	1, 500 W (max)
