the level of CLK. For details, refer to descriptions in

Trigger Level

. The current

trigger level is displayed in the trigger information label at the top of the screen.

• Level B

Click or tap the input field of Level B to input the level of MISO with the pop-up

numeric keypad. You can also use the corresponding multipurpose knob to

adjust the level of MISO. When the level B information is displayed in the trigger

label, you can also use the trigger level knob to adjust the level of MISO. For

details, refer to descriptions in

Trigger Level

. The current trigger level is displayed

in the trigger information label at the top of the screen.

• Level C

Click or tap the input field of Level C to input the level of CS with the pop-up

numeric keypad. You can also use the corresponding multipurpose knob to

adjust the level of CS. When the level C information is displayed in the trigger

label, you can also use the trigger level knob to adjust the level of CS. For details,

refer to descriptions in

Trigger Level

. The current trigger level is displayed in the

trigger information label at the top of the screen.

8.8 Trigger Output Connector

The rear-panel trigger output connector ([AUX OUT]) of this series can output trigger

signals determined by the current setting (hardware trigger).

Click or tap

> Utility. Click or tap Setup, and then select "TrigOut" in Aux Out. A

signal which reflects the current oscilloscope capture rate can be output from [AUX

OUT] connector each time a trigger is generated by the oscilloscope. If this signal is

connected to a waveform display device to measure the frequency, the measurement

result is the same as the current capture rate.

If "PassFail" is selected in Aux Out, the instrument can output a pulse from the [AUX

OUT] connector when a pass/failed event is detected during the pass/fail test.

Triggering the Oscilloscope

DHO800 User Guide

104
