24.3 Appendix C: Factory Settings

Press the front-panel or click/tap Default on the Toolbar and a prompt

message "Restore default settings?" is displayed. Click or tap

OK to restore the

instrument to its factory default settings, as shown in the table below.

Table 24.2 Factory Settings

Parameter Factory Settings

Horizontal

Horizontal Time Base 2 μs

Horizontal Position 0 s

Delayed Sweep OFF

Roll Auto

Fine OFF

Horizontal Expansion Center

Acquisition

Acquisition Mode Normal

Memory Depth 10 kpts

Vertical

CH1 On/Off ON

CH2 On/Off OFF

CH3 On/Off OFF

CH4 On/Off OFF

Impedance 1 MΩ

Fine OFF

Vertical Scale 50 mV

Vertical Offset 0 V

Channel Unit [V]

Channel Coupling DC

Bias 0 V

BW Limit OFF

Channel Delay 0 s

Display Label OFF

Invert OFF

Attenuation 1X

Trigger

Trigger Type Edge Trigger

Trigger Mode Auto

Appendix
