Model
A 24-byte character array in the format of MODEL#:SERIAL#,
indicating the oscilloscope's model and serial number.
Channel Name
A 16-byte character array that contains the label assigned to
the waveform.
3. Waveform Data Header
A waveform may have multiple data sets. Each waveform data set has a waveform
data header. The waveform data header consists of information about the
waveform data set. The header is stored before the data set.
Table 20.4 Waveform Data Header
Header Size
A 4-byte integer, indicating the number of bytes in the
waveform data header.
Buffer Type
A 2-byte integer, indicating the type of the waveform data
stored in the file.
- 0 = Unknown
- 1 = Normal 32-bit float data
- 2 = Maximum float data
- 3 = Minimum float data
- 4 = Not Used
- 5 = Digital unsigned 8-bit character data (for digital
channels)
Bytes Per Point
A 2-byte short integer, indicating the number of bytes per
data point.
Buffer Size
An 8-byte long integer, indicating the number of bytes of the
current channel waveform data.
20.3 To Load a File
In the storage setting menu, click or tap the Load tab to switch to the load menu. In
this menu, you can load the local file to the instrument.
Store and Load
Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. DHO800 User Guide
209
