• WebControl
Indicates the version number of browser remote control module.
21.4 Other Settings
Open Source Acknowledgment
Click or tap
Open Source Acknowledgment to view the open source
acknowledgment of this series oscilloscope in the pop-up window.
21.5 Auto Config
In "Utility" menu, click or tap Auto Config to enter the menu in which you can
configure the
Auto function.
• Click or tap
Peak to Peak on/off switch to enable or disable the peak-to-peak
priority setting. This function is intended for the shifted signal. If there is a large
deviation, you can view the signal waveform in priority when you enable the
function.
• Click or tap
Live CH on/off switch to turn on/off examining channels that are
turned on.
If "OFF" is selected, enable the Auto function and 4 analog channels (CH1-CH4)
will be examined for signal activity in sequence. If no signal is detected for a
specified channel, the channel will be turned off; otherwise, if a signal is
detected, the channel will be autoscaled to best display the signal. If “ON” is
selected, enable the Auto function and only the channels that are turned on will
be examined.
• Click or tap Overlay on/off switch to enable or disable the waveform overlay
display function. If enabled, waveforms of different channels will be displayed in
the same position of the screen; if disabled, waveforms of different channels will
be displayed on the screen from top to bottom in sequence.
• Click or tap Keep Coupling on/off switch to turn on/off maintaining channel
coupling. If "ON" is selected, enable the Auto function and the channel coupling
setting is maintained; if "OFF" is selected, the channel coupling is DC coupling by
default.
System Utility Function Setting
Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. DHO800 User Guide
219
