Parts List: Option 1, 1768-L43 and 1768-L45 Systems with EtherNet/IP
The table lists the parts for the 1768-L43 and 1768-L45 systems with an EtherNet/IP
network and a 200/230V Kinetix 6000 Multi-axis Servo Drive System.
Parts List: Option 1, 1768-L43 and 1768-L45 Systems with EtherNet/IP Network

Quantity Catalog Number Description
General Configuration
1 1768-L43 and 1768-L45 CompactLogix Controller
1 1768-PA3 CompactLogix Power Supply
1 1769-ECR Compact I/O Right End Cap/Terminator
1 1769-IF4 Compact 4 Channel Analog Current/Voltage Input Module
1 1769-IQ16 Compact 16 Point 24V dc Sinking/Sourcing Input Module
1 1769-IF4XOF2 Compact 8 Bit Resolution, High Speed 4 In/2 Out Analog Combination Module
1 1769-OF2 Compact 2 Channel Analog Current/Voltage Output Module
1
1769-OB16
(1)
Compact 16 Point 24V dc Sourcing Output Module
1
1734-IB4
(2)
POINT I/O 4 Sink Input Module
1
1734-OB4E
(2) (3)
POINT I/O 4 Protected Output Module
1
1734-OE2C
(2)
POINT I/O 2 Current Output Analog Module
1 1734-TB Wiring Base w/ Removable IEC Screw Terminals (Quantity of 10)
1 1794-PS13 FLEX I/O 85-264V ac to 24V dc 1.3A Power Supply
1 20AB4P2A3AYNNNNN PowerFlex 70 Drive.
1 2711P-B10C4D1 PanelView Plus 10 inch color keypad/touch terminal with EtherNet/IP and RS-232
1 1747-CP3 or 1756-CP3 RS-232 cable for connection between the 1768-L43 controller and personal computer
1 64-134 DIN rail (steel not aluminum), 1 m
EtherNet/IP Configuration
1 1768-ENBT CompactLogix EtherNet/IP Communication Module
1 1734-AENT POINT I/O Ethernet Adapter
1 20-COMM-E PowerFlex 70 EtherNet/IP Adapter
1 Ethernet Switch
6 Non Rockwell Automation Ethernet CAT5 Straight-through cables
