Rockwell Automation Publication 2715P-UM001C-EN-P - March 2019 43
Chapter 3
Configure Terminal Settings
Runtime Environment
During runtime, the PanelView™ 5510 terminal runs HMI projects. A project is
configured and downloaded to your terminal from the View Designer
application. The project launches each time the terminal restarts.
The terminal exchanges data values with the controller, animates the displayed
data, and responds when you press keys or touch a screen or element on a screen.
During runtime, you can perform these tasks:
• Navigate screens and their graphic elements
• View and manage alarms
• View and perform operations on a trend chart
• Display error information
• Configure terminal settings and view diagnostic information
Topic Page Topic Page
Runtime Environment 43 Calibrate the Touch Screen 58
Enter Data With Virtual Keyboards 45 Disable Downloads to the Terminal 60
Log On to the Terminal 47 Change the HMI Device Name 61
Log Off of the Terminal 48 View the Firmware Revision 62
Settings Menu 48 Display Terminal Diagnostics 63
Configure the IP Address of the Terminal 50 Enable the VNC Server 64
Configure a DNS Address For the Terminal 52 Load an Application from Removable
Media
65
Configure the Ethernet Ports 53 Enable the VNC Server 64
View the Network Diagnostics 54 Change the Date and Time 67
Export a Data Log 55 View General Information for the
Configured Controller
68
Configure the Display Screen Saver 57
To Next Page
