Rotex GW User Manual

29
FA ROTEX GW - 09/2012
6 x Operation
6.5.2 End-user level (E1)
Ɣ Activate the basic display.
Ɣ Press the key for 3 s.
Î End-user level (E1) is activated.
Î The 1st. parameter is displayed (display automatically
changes each second between the 1st. + 2nd. part of the
parameter, e.g. P6 ->81->P6->81 = P681).
Ɣ Select the next parameter with the buttons / or
leave the level by pressing button briefly.
6.5.3 Heating technician level (E2)
Ɣ Activate the basic display.
Ɣ Press the key for 3 s.
Î End-user level (E1) is activated.
Î The 1st. parameter is displayed (display automatically
changes each second between the 1st. + 2nd. part of the
parameter, e.g. P6 ->81->P6->81 = P681).
Ɣ Press button again for 3 secs.
Î Message "on" is displayed.
Î Heating technician level (E2) is activated.
Î The 1st. parameter is displayed (display automatically
changes each second between the 1st. + 2nd. part of the
parameter, e.g. P5 ->18->P5->18 = P518).
Ɣ Select the next parameter with the buttons / or
leave the level by pressing button briefly.
Fig. 6-10 Jump to the end-user level and setting a bit parameter value
(example: P681 - bit7 changed from "off" to "on")
This resets the parameters to the factory settings.
E0
E1
3s
45
°C
P6
8 1
7x
of
on
b0
b7
Fig. 6-11 Jump to the heating technician level and setting a parameter
value (example: P518 - value changed from "0" to "5")
This limits the increase in boiler nominal value temperature on a ramp
function with 5 K/min.
E1
E0
E2
3s
3s
5x
45
°C
P6
8 1
on
P5
1 8
0
5
