Rotex GW User Manual

30
FA ROTEX GW - 09/2012
6 x Operation
6.5.4 Parameter list
Tab. 6-4 List of settable parameters
Parameter
no.
Level Explanation Setting range Factory
value
Increm
ent
P518
E2
To reduce the thermal load on the burner the boiler nominal value increase can, in
the heating mode, be limited by a ramp function. This prevents large load jumps up-
wards.
The ramp function can be switched on in a range from 1 K/min to 15 K/min. A nominal
value, calculated from the controller algorithm, will then be limited by this value during
nominal value jumps upwards.
Setting 0: Function switched off
0 - 15 K/min 0 1 K/min
P520 Not applicable 0 - 10 K 0
1)
1K
P532 Heating characteristic line gradient direct heating circuit with connected external tem-
perature sensor (see fig. 6-12).
This function permits manual adaption of the heating characteristic line to the building
and the individual demands with weather-dependent control.
1 - 40 24 1
P541 Limiting the maximum heating output in room heating mode
The output limitation does not affect the hot water operating mode.
Setting changes must be entered on the setting identification plate and in the operat-
ing handbook. 0% = Q
min
/ 100% = Q
max
0 - 100 % 0 1 %
P555 Setting options for unit frost protection and room thermostat input:
on / off -
b0 / b1: Not assigned off
1)
b2: off = room station
on = timer
off
b3: Not assigned off
1)
b4: Unit frost protection function on
1)
b5 - b7: Not assigned off
1)
P651 Gas type setting (this value is not reset during a RESET!)
1: Natural gas E/H
2: Liquefied petroleum gas
3: Elevated minimum output
1 - 3 1 1
P652 Selection of a pre-configured heat distribution system. For pre-setting of certain pa-
rameter sets for heating systems (max. flow temperature T
Vmax
at standard external
temperature, boiler nominal ramp function K
R
- corresponding to P518, heating char-
acteristic line gradient S - corresponding to P532).
0: Current dataset when unit delivered, T
Vmax
= 70 °C, K
R
= 0, S = 15
1: Renovation, radiator, T
Vmax
= 85 °C, K
R
= 5, S = 24
2: Renovation, radiator, T
Vmax
= 70 °C, K
R
= 5, S = 19
3: New-build, radiator, T
Vmax
= 60 °C, K
R
= 3, S = 15
4: New-build, radiator, T
Vmax
= 50 °C, K
R
= 3, S = 11
An automatic restart takes place automatically after re-setting this parameter value.
The new values are accepted into the current dataset 0, and the parameter value of
P652 once again is at 0.
0 - 4 0 1
P680 Not applicable 0 - 10 0
1)
1
P681 E1 Execute RESET:
on / off -
b0 - b6: Not assigned off
1)
b7: on = restart with factory settings
The value of P651 is not reset. The effect of the function depends on which
user level initiates it.
off
P682 E2 b0 - b7: Not applicable on / off off
1)
-
P683 E2 Percentage increase of burner blower speed with minimum output and start. To be
used under very difficult wind conditions, with an unfavourable arrangement of ex-
haust system or in the event of burner start problems or burner noises.
0 - 20 % 0 1 %
P684 E1 Special functions for heating circulation pump.
on / off -
b0 (manual unit frost protection):
on = Continuous pump running
off = Pump off if no heat demand exists
off
b1 (continuous flow heater mode):
on = Comfort
off = ECO
on
1)
b2 - b7: Not assigned off
1)
P686 E2 Not applicable 1 - 500 300
1)
1
E1 Can be set by end-user and heating technician via operating elements direct on the controller
E2 Can only be set by heating technician via operating elements direct on the controller
1) The factory values must not be changed! In the event of other settings, the manufacturer's warranty lapses automatically!
