Switching between summer and winter time:
LOGO! must be in RUN if you want to switch over the time.
1. If necessary, exit programming or parameterization
mode and switch LOGO! to RUN.
Time displayed Mo 09:17
I:12345678
9 10 11 12
Q:12345678
2. Press OK and
The current time is put forward by one hour.
Time displayed after
change
Mo 10:17
I:12345678
9 10 11 12
Q:12345678
Change the time in the opposite direction in the same way:
3. Press OK and
The current time is put back by one hour.
Time displayed after
change
Mo 09:17
I:12345678
9 10 11 12
Q:12345678
Parameterizin
g
LOGO!

Siemens LOGO! 24 Specifications

General

Dimensions	90 x 72 x 55 mm
Relay Outputs	4
Programming	LOGO! Soft Comfort
Mounting Type	DIN Rail
Protection Class	IP20
Inputs	8 Digital
Outputs	4 Relay
Output Current	10 A per relay output
Operating Temperature	0 ... 55 °C
Display	LCD with backlight
