LOGO! Manual
A5E00067781 01
LOGO! 24RCL
LOGO! 24RCLB11
LOGO! 24L
Digital outputs
Number 8 8
Output type Transistor, current–
sourcing
Relay outputs
Electrical isolation No Yes
In groups of 2
Activation of digital input Yes Yes
Output voltage  Supply voltage
Output current Max. 0.3 A
Continuous current I
th
(per
connector)
Max. 10 A
Incandescent lamp load
(25,000 switching cycles) at
1000 W
Fluorescent tubes with electr.
control gear (25,000 switch-
ing cycles)
10 x 58 W
Fluorescent tubes, conven-
tionally compensated (25,000
switching cycles)
1 x 58 W
Fluorescent tubes, uncom-
pensated (25,000 switching
cycles)
10 x 58 W
Short circuit–proof and over-
load–proof
Yes
Short–circuit current limitation Approx. 1 A
Derating None throughout
the entire tempera-
ture range
None throughout
the entire tempera-
ture range
Short circuit–proof cos 1 Power protection
B16
600A
Technical Specifications

Siemens LOGO! 24 Specifications

General

Dimensions	90 x 72 x 55 mm
Relay Outputs	4
Programming	LOGO! Soft Comfort
Mounting Type	DIN Rail
Protection Class	IP20
Inputs	8 Digital
Outputs	4 Relay
Output Current	10 A per relay output
Operating Temperature	0 ... 55 °C
Display	LCD with backlight
