Siemens LOGO! 24 User Manual

89
LOGO! Manual
A5E00067781 01
S
n
R
n
Q
Remarks
0
0 x State remains the same
01 0Reset
10 1
Set
11 0Reset (resetting has priority over setting)
After power failure the signal that was valid before the
power failure is set at the output if the retentive feature was
switched on.
LOGO! Functions

Siemens LOGO! 24 Specifications

General

Dimensions	90 x 72 x 55 mm
Relay Outputs	4
Programming	LOGO! Soft Comfort
Mounting Type	DIN Rail
Protection Class	IP20
Inputs	8 Digital
Outputs	4 Relay
Output Current	10 A per relay output
Operating Temperature	0 ... 55 °C
Display	LCD with backlight
