Product properties
3.28 Displays
SCALANCE X-200
120 Operating Instructions, 12/2011, A5E00349864-19
3.28 Displays
3.28.1 Fault indicator (red LED)
Fault indicator (red LED)
If the red LED is lit, the IE Switch X-200 has detected a problem.
The signaling contact opens at the same time provided that the behavior of the signaling
contact was not configured differently.
The LED signals that the IE Switch X-200 can adopt the following statuses:
Device type SCALANCE LED lit red LED flashing red LED not lit
XF204 1, 2, 3, 4, 5, 6, 10 9 11
X208 1, 2, 3, 4, 5, 6, 10 9 11
XF208 1, 2, 3, 4, 5, 6, 10 9 11
X216 1, 2, 3, 4, 5, 6, 10 9 11
X224 1, 2, 3, 4, 5, 6, 10 9 11
X204-2 1, 2, 3, 4, 5, 6, 10 9 11
X204-2TS 1, 2, 3, 4, 5, 6, 10 9 11
XF204-2 1, 2, 3, 4, 5, 6, 10 9 11
X206-1 1, 2, 3, 4, 5, 6, 10 9 11
XF206-1 1, 2, 3, 4, 5, 6, 10 9 11
X212-2 1, 2, 3, 4, 5, 6, 10 9 11
X204-2LD 1, 2, 3, 4, 5, 6, 10 9 11
X206-1LD 1, 2, 3, 4, 5, 6, 10 9 11
X212-2LD 1, 2, 3, 4, 5, 6, 10 9 11
X202-2IRT 1, 2, 3, 4, 5, 6, 7 9 11
X204IRT 1, 2, 3, 4, 5, 6, 7 9 11
XF204IRT 1, 2, 3, 4, 5, 6, 7 9 11
X204 IRT PRO 1, 3, 4, 5, 6, 7 9 11
X202-2P IRT PRO 1, 3, 4, 5, 6, 7, 8 9 11
X201-3P IRT PRO 1, 3, 4, 5, 6, 7, 8 9 11
X202-2P IRT 1, 2, 3, 4, 5, 6, 7, 8 9 11
X201-3P IRT 1, 2, 3, 4, 5, 6, 7, 8 9 11
X200-4P IRT 1, 2, 3, 4, 5, 6, 7, 8 9 11
