3.28 Displays
SCALANCE X-200
Operating Instructions, 12/2011, A5E00349864-19
123
3.28.3 Port status indicator (green/yellow LEDs)
Port status indicator (green/yellow LEDs)
The LEDs signal that the IE Switch X-200 can adopt the following statuses.
The status of the interfaces is indicated by two-color LEDs:
Device type SCALANCE
Number of port
LEDs
LED lit green LED lit yellow LED flashes
yellow
LED flashes
green
XF204 4 port LEDs 1 2, 3 4 5, 6
X208 8 port LEDs 1 2, 3 4 5, 6
XF208 8 port LEDs 1 2, 3 4 5, 6
X204-2 6 port LEDs 1 2, 3 4 5, 6
X204-2TS 6 port LEDs 1 2, 3 4 5, 6
XF204-2 6 port LEDs 1 2, 3 4 5, 6
X206-1 7 port LEDs 1 2, 3 4 5, 6
XF206-1 7 port LEDs 1 2, 3 4 5, 6
X204-2LD 6 port LEDs 1 2, 3 4 5, 6
X206-1LD 7 port LEDs 1 2, 3 4 5, 6
X202-2IRT 4 port LEDs 1 2, 3 4 5, 6
X204IRT 4 port LEDs 1 2, 3 4 5, 6
XF204IRT 4 port LEDs 1 2, 3 4 5, 6
X204 IRT PRO 4 port LEDs 1 2, 3 4 5, 6
X202-2P IRT PRO 4 port LEDs 1 2, 3 4 5, 6
X201-3P IRT PRO 4 port LEDs 1 2, 3 4 5, 6
X202-2P IRT 4 port LEDs 1 2, 3 4 5, 6
X201-3P IRT 4 port LEDs 1 2, 3 4 5, 6
X200-4P IRT 4 port LEDs 1 2, 3 4 5, 6
X216 16 port LEDs 1 2, 3 4 5, 6
X212-2 14 port LEDs 1 2, 3 4 5, 6
X212-2LD 14 port LEDs 1 2, 3 4 5, 6
X224 24 port LEDs 1 2, 3 4 5, 6
1. TP link exists, no data reception.
2. TP link, data received at TP port.
3. Device startup, the LED is lit for approx. 6 seconds.
4. Setting or display of the fault mask.
5. The "Show Location" function was enabled over Ethernet (for example, PST tool).
The button was pressed for longer than 15 seconds to reset the configuration.
6. PROFINET IO operation was started with the PN IO controller, the attempt to change the
fault mask with the button was rejected by all the port LEDs flashing once.
