Connection
5.5 Fitting the IE RJ 45 Plug Pro and IE SC RJ Plug Pro
SCALANCE X-200
Operating Instructions, 12/2011, A5E00349864-19
145
5.5 Fitting the IE RJ 45 Plug Pro and IE SC RJ Plug Pro
IE RJ 45 Plug Pro and IE SC RJ Plug Pro
You will find the instructions for assembling a SIMATIC NET Industrial Ethernet cable with
the industrial IE RJ-45 Plug Pro or IE SC RJ Plug Pro in the documentation supplied with the
connectors.
Figure 5-6 IE RJ 45 Plug Pro or IE SC RJ Plug Pro
Inserting the IE RJ 45 Plug Pro or IE SC RJ Plug Pro
1. Insert the IE RJ 45 Plug Pro or IE SC RJ Plug Pro until they click in place in the IE
Switches X-200.
Figure 5-7 IE RJ 45 Plug Pro or IE SC RJ Plug Pro inserted
Removing the IE RJ 45 Plug Pro or IE SC RJ Plug Pro
1. Remove IE RJ 45 Plug Pro or IE SC RJ Plug Pro from the socket of the IE Switches X-
200.
Figure 5-8 Removing IE RJ 45 Plug Pro or IE SC RJ Plug Pro
