Configuration / diagnostics using remote mechanisms
6.3 Configuration using Web Based Management (WBM) and Command Line Interface (CLI)
SCALANCE X-200
240 Operating Instructions, 12/2011, A5E00349864-19
Table 6- 37 Variables in the Interface directory
Variable Access rights Description
ifNumber Read only The number of different interfaces available in the component.
Possible values: 4 - 8
ifDescr Read only A description and possibly additional information for a port. Possible
value: string with a maximum of 255 characters
ifType Read only The value ethernet-csmacd(6) or optical(65) is entered for
SCALANCE X-200.
ifSpeed Read only Data transfer rate of the Ethernet port in bits per second. With
SCALANCE X-200 devices, this is either 10 Mbps or 100 Mbps
ifOperStatus Read only The current operating status of the Ethernet port. The following values
are possible: ● up(1) ● down(2)
ifLastChange Read only Length of time for which the selected port has been operating in the
current status. The value is shown in hundredths of a second.
ifInErrors Read only Number of received packages that were not forwarded to higher protocol
layers because of an error.
ifOutErrors Read only Number of packages that were not sent because of an error.
Port Indexes
The interface index must be used for port designations. The following table shows how the
interface indexes are assigned to the ports.
Interface Index Port
1 Port 1
2 Port 2
3 Port 3
4 Port 4
5 Port 5
6 Port 6
7 Port 7
8 Port 8
.
.
.
.
.
:
24 Port 24
Important private MIB variables of an IE Switch X-200
OID The private MIB variables of the IE Switch X-200 have the following object identifier:
iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).
ad(4196).adProductMibs(1).simaticNet(1).iScalanceX(5).iScalanceX200(2)
