A-1
Equipment Manual OP7, OP17
Release 04/99
Brief Description of Standard Screens
The
table below presents an overview of all the standard screens for Operating Panels OP7 and OP17.
Apart from a brief comment on functions, mention is made of the requisite password level. The ”Level
1” column lists the screens that you can choose from the basic screen. These screens allow you to make
dif
ferent calls, which are listed under ”Level 2”.
Level 1 Level 2 Function Password Level
Alarms → View Display alarm messages in alarm buffer
Display message text for message selected in alarm buffer.
0
Alarms → Print
Print alarm messages as
history
, i.e. all message events (arrive, depart,
acknowledge) in chronological order of their occurrence.
2
Alarms → Number Display
the messages entered in buf
fer
, divided into ’messages over
-
all’ and ’queuing messages’.
0
Alarms → Delete Delete all acknowledged and departed alarm messages from the buffer. 6
Alarms → Overflow Enable and disable a system message upon over flow of the alarm
buffer.
4
Alarms → Text Display all text elements of alarm messages 0
Events → View Display event messages in event buffer.
Display message text relating to a message selected in event
buffer.
0
Events → Print Print
event messages as history
, i.e. all message events (arrive, depart)
in chronological order of their occurrence.
2
Events → Number Display
messages entered in the buf
fer
, divided into ’messages over
-
all’ and ’queuing messages’.
0
Events → Delete Delete all event messages in the event buffer that have arrived and
departed.
6
Events → Overflow Enable and disable system message upon overflow of event buffer. 4
Events → Text Display all text elements of event messages 0
Screens → Edit Display directory for screens.
Display screens and edit fields
0
Screens → Print Display directory for screens.
Output selected screen to printer.
2
A
