Siemens simatic hmi op7 User Manual

A-2
Equipment Manual OP7, OP17
Release 04/99
Function Password LevelLevel 2Level 1
Record→ Edit  Display directories for recipes
 Display and edit data records
1
Record→ Transfer  Copy data record
 Transfer data record from PLC to OP
 Fetch data record from PLC to OP
1
Record→ Print Print recipe with selected data record 2
System settings
→
OPMode Set OP operating modes:
Online, Offline, Download, Loop-through
8
System settings
→
DispMsg Set whether the oldest (first) or latest (last) alarm message is dis-
played when there is more than one message waiting.
4
System settings
→
SysMsg Display system buffer. 0
System settings
→
Language Select language. 2
System settings
→
Dat/Time Set date and time 4
System settings
→
Printer Set printer parameters. 2
System settings
→
IF1A/RS232
IF1A/TTY
IF1B
IF1A/B
IF2
OP7 only:
Set interface parameters.
OP17 only:
Set interface parameters.
6
StatVAR Display S5S7 operands 0
ForceVAR Display and modify S5S7 operands. 8
Password
processing →
Login Log in a user by entering a password. 0
Password
processing →
Logout Log out a user and branches backward to message level. 0
Password
processing →
Edit  Display password list.
 Allocate and modify passwords and password levels.
 Delete passwords.
9
