4.2 Install example image on eMMC
SIMATIC IOT2050
36 Operating Instructions, 03/2024, A5E39456816-AF
4.2 Install example image on eMMC
4.2.1 Overview
This chapter describes how to install the example image on the eMMC of the IOT2050.
eMMC, this procedure is not applicable for IOT2050 Basic (6ES7647-
Procedure
The installation includes the following procedures:
1. Use engineering station to flash the example image to the first USB flash drive or SD card
using, for example, Win32DiskImager.
2. Power on IOT2050 (Page 31).
3. Install the example image on eMMC of the IOT2050 in one of the following two ways:
– Use a single USB flash drive / SD card
– Use two different USB flash drives / SD card
- One to run the Example Image
- One to transfer the Example Image to the eMMC
Required Hardware
SD card or USB flash driver.
The internal eMMC can also be used.
To remotely access the IOT2050 and transfer files, an engineering sta-
tion is required. In this document, a PC running Windows 10 Enterprise
is used.
The Engineering Station must include the following interfaces:
• SD card slot
• Ethernet port
For connecting the engineering station to the IOT2050 using SSH.
DisplayPort Cable (Male-
Male) and Monitor
For connecting to a local IOT2050
For connecting to a local IOT2050
