Technical specifications
9.1 IOT2050 SM
SIMATIC IOT2050
Operating Instructions, 03/2024, A5E39456816-AF
97
LAN interface
P1 - X1 LAN - P2, RJ45
1
1 GB LAN port
COM X30
• RS232
2
, max. 115 Kbps, D-sub connector, 9-pin
• RS422
2 3
, max. 115 Kbps, D-sub connector, 9-pin
• RS485
2 3
, max. 115 Kbps, D-sub connector, 9-pin
1
For unique labeling, the LAN interfaces are numbered on the enclosure. The numbering by
the operating system can differ. Siemens recommends you use shielded ethernet cables.
2
You can use any COM port as an RS232, RS422 or RS485 interface through the software-
controlled interface parameter assignment.
3
Termination with 120 Ω terminal resistance can be set with the software.
The maximum cable length is 1000 m under the following preconditions:
•
Data signaling rate is below 90Kbps
•
Using twisted pair copper wire of 24AWG or larger diameter
Additional information on parameter assignment is available in the SIMATIC IOT2000-Forum,
see section "Software and commissioning (Page 35)".
9.1.2 Electromagnetic compatibility
Emission
Radiated emission according to IEC 61000-6-4, measuring distance 3 m
Frerangequency
Interference emission
30 to 230 MHz
< 50 dB (μV/m) quasi-peak
230 to 1000 MHz
< 57 dB (μV/m) quasi-peak
1 to 3 GHz
< 76 dB (μV/m) peak and < 56 dB (μV/m) average
3 to 6 GHz
< 80 dB (μV/m) peak and < 60 dB (μV/m) average
Emission of radio interference voltages according to IEC 61000-6-4
Emission port
Interference emission
Power port
0.15 to 0.5 MHz
< 79 dB (μV) quasi peak and < 66 dB (μV) average
0.5 to 30 MHz
< 73 dB (μV) quasi peak and < 60 dB (μV) average
Telecommunication / Network port
0.15 to 0.5 MHz
< 97 dB (μV) to 87 dB (μV) quasi peak and < 84 dB (μV) to 74 dB (μV) average
0.5 to 30 MHz
< 87 dB (μV) quasi peak and < 74 dB (μV) average
