SIMATIC IOT2050
96 Operating Instructions, 03/2024, A5E39456816-AF
Technical specifications
9.1 IOT2050 SM
9.1.1 General technical specifications
General technical specifications
Weight without mounting brackets
1
24 VDC (20.4 to 28.8 V), no galvanic isolation
Brief voltage interruption in accord-
ance with Namur
Up to 10 ms buffer time at 24 V DC and full load
2
Max. 10 events per hour; recovery time at least 10 ms
Max. power consumption 30W
< 40 dB(A) according to DIN 45635-1
IP20 according to IEC 60529
Protection class III in accordance with IEC 61140
Device is designed for environments with pollution degree 2
13.8 years. This was calculated under conditions of a tempera-
ture of 40 °C and a workload of 100%.
In accordance with ISO 9001
1
The device should only be connected to a power supply which meets the requirements of safe
extra low voltage (SELV) according to IEC/EN/DIN EN/UL 61010-1.
2
In the event of low supply voltage, the buffer time is reduced
Motherboard
TI Sitara AM6548 HS, 1000 MHz
Slot for one Micro SD card
Slot for one Nano SIM card
1 x mini PCIe for PCIe cards 30 x 50.59 mm or 30 x 26.8 mm
Interfaces
Interface for S7-1200 SM modules only
