Siemens SIMATIC IOT User Manual

Technical specifications
9.1 IOT2050 SM
SIMATIC IOT2050
Operating Instructions, 03/2024, A5E39456816-AF
99
• Operation
5 to 95% at 30°C, no condensation
• Storage/transport
5 to 95 % at 25/55 °C, no condensation
Atmospheric pressure, Altitude
• Operation
1080 to 795 hPa, corresponds to an elevation of -1000 m to 2000 m
• Storage/transport
1080 to 660 hPa, corresponds to an elevation of -1000 to 3500 m
* Also note the following section "Power consumption of the components".
Mechanical ambient conditions
Vibration resistance, tested in accordance with IEC 60068-2-6
• Operation
Vibration load 1g, 10 cycles per axle:
• 5 to 8.4 Hz, deflection 3.5 mm
• 8.4 to 200 Hz, acceleration 9.8 m/s
2
• Storage/transport • 5 to 8.4 Hz: Deflection 3.5 mm
• 8.4 Hz to 500 Hz: Acceleration 9.8 m/s
2
Impact resistance, tested in accordance with IEC 60068-2-27
• Operation
150 m/s
2
, 11 ms
• Storage/transport
250 m/s
2
, 6 ms
9.1.4 Power demand of the components
Maximum power consumption of the auxiliary components
For the ambient temperature for permitted mounting position, refer to Ambient conditions
(Page 98).
Auxiliary com-
ponents
Maximum permitted power
consumption
Maximum total power
+5 V
+3.3 V
+1.5 V
All components
6.5 W
Mini PCIe card
--
1.5 A
1
0.3 A
2
Permitted power distribution
• Mini PCIe card: 5.6 W
3
; USB: 2.5 W
USB 2.0 high
current
500 mA
--
--
Interface for S7-
1200 SM mod-
ules
1200 m
A
--
--
1
May amount to maximum 3.0 A for up to 100 ms at start-stop torque of device
2
May amount to maximum 1.2 A for up to 100 ms at start-stop torque of device
3
Long-term operation under high-temperature conditions at an average load of 5.6W is not rec-
ommended.
