Technical data
12.1 Dimension drawings
TP 270, OP 270, MP 270B (WinCC flexible)
Operating Instructions, Edition 03/2004, 6AV6691-1DD01-0AB0
12-3
12.1.3 Dimensions, MP 270B 10" Keys, OP 270 10"
Unit dimensions
MP 270B Keys and OP 270 10" HMI device dimensions:
The two devices only differ on the front by their
!
e-establ ("SIMATIC MULTI PANEL" on the
MP 270B 10" Keys, "SIMATIC PANEL" on the TP 270 10").
482.6
310.3
288.3
(58.6)
9.5
55.3
431.6
Side viewFront view
Plan view
Figure 12-3 Dimensions of the MP 270B 10" Keys and OP 270 10"
