1 General notes
1.1 Validity
This document is valid for ventilation units with reverse curved impeller and ECblue fan of motor size
B (090).
The used motor size is recognisable from the type designation (
rating plate).
e. g.:. Type: GR31M-6ID.BD.2R
In the case of fans with the quality mark (
rating plate), please note the related specifications
depending on the application location.
1.2 Structure of the assembly instructions
Before installation and start-up, read this assembly instructions carefully to ensure correct use!
We emphasize that these assembly instructions apply to specific units only, and are in no way
valid for the complete system!
Use these assembly instructions to work safely with and on the device. They contain safety instruc-
tions that must be complied with as well as information that is required for failure-free operation of the
device.
Keep these assembly instructions together with the device. It must be ensured that all persons that
are to work on the device can refer to the assembly instructions at any time.
Keep the assembly instructions for continued use. They must be passed-on to all successive owners,
users and final customers.
1.3 Target group
The assembly instructions address persons entrusted with planning, installation, commissioning and
maintenance and servicing and who have the corresponding qualifications and skills for their job.
1.4 Exclusion of liability
Concurrence between the contents of these assembly instructions and the described hardware and
software in the device has been examined. It is still possible that non-compliances exist; no guarantee
is assumed for complete conformity. To allow for future developments, construction methods and
technical data given are subject to alteration. We do not accept any liability for possible errors or
omissions in the information contained in data, illustrations or drawings provided.
ZIEHL-ABEGG SE is not liable for damage due to misuse, incorrect use, improper use or as a
consequence of unauthorized repairs or modifications.
1.5 Copyright
These assembly instructions contain copyright protected information. The assembly instructions may
be neither completely nor partially photocopied, reproduced, translated or put on data medium without
previous explicit consent from ZIEHL-ABEGG SE. Infringements are liable for damages. All rights
reserved, including those that arise through patent issue or registration on a utility model.
Assembly instructions ECblue General notes
L-BAL-F065-GB 1617 Index 004 Part.-No. 00702801-GB
4/28
