Siemens SIMOTICS M-1PH8 User Manual

Table 3-1 Elements on the rating plate
No. Description No. Description
010 MLFB 170 Rated speed n
N
(2)
012 Consecutive number, part of serial number 180 Operating mode (2)
020 Serial number 185 Code for operating point 2
025 UL approval 190 Rated voltage V
N
(3)
026 (Empty) 191 Switching mode 3
030 Type of construction 200 Rated current I
N
(3)
035 (Empty) 210 Rated power P
N
(3)
036 (Empty) 220 Induced voltage U
I
[V] (3)
040 Degree of protection 230 Rated frequency f
N
(3)
045 Type of balancing 240 Rated speed n
N
(3)
050 Rated voltage U
N
(1) 250 Operating mode (3)
051 Connection type 1 255 Code for operating point 3
060 Rated current I
N
(1) 330 Maximum current I
MAX
070 Rated power P
N
(1) 335 Weight
080 Induced voltage U
I
[V] (1) 340 Maximum torque M
MAX
090 Rated frequency f
N
(1) 350 Maximum speed n
MAX
100 Rated speed n
N
(1) 360 Temperature sensor
110 Operating mode (1) 370 Tachometer/resolver
115 Code for operating point 1 380 Cooling method
120 Rated voltage U
N
(2) 390 Throughput l/min (m
3
/s)
121 Connection type 2 400 System pressure
130 Rated current I
N
(2) 410 Maximum coolant temperature
140 Rated power P
N
(2) 420 Options (I)
150 Induced voltage U
I
[V] (2) 430 Options (II)
160 Rated frequency f
N
(2) 440 Optional customer information
450 Anti-condensation heater / place holder
Rotor
This machine is a synchronous motor for low voltage with the permanent magnet rotor and
integrated cooling circuit.
See also
Working on machines with permanent magnets (Page 16)
Description
SIMOTICS M-1PH8 1PH818., 1PH822.
22 Operating Instructions 07/2016
