5.1.4 Prepare the mounting surfaces (IM B3)
● Ensure that the foundation faces are flat and clean.
● Check the dimensions of the mounting-foot holes.
5.1.5 Prepare the mounting surfaces (flange mounting)
● Clean the flange before installation, and make sure that the flange face is flat and free of
contaminations.
● Check the geometry of the flange.
5.2 Lift the machine to where it will be mounted and position it
5.2.1 Preconditions for correct alignment and secure attachment
Detailed specialist knowledge of the following measures is required in order to correctly align
and securely fit the equipment.
● Preparing the foundation
● Selecting and mounting the coupling
● Measuring the concentricity and axial eccentricity tolerances
● Positioning the machine
If you are not familiar with the prescribed measures and procedures, then you can make use
of the services offered by the local Service Center (Page 131).
5.2.2 Checking the load handling attachments
Inspect the load handling attachments such as the load stands, lifting eyes and ring bolts and
also the lifting gear, before lifting the machine:
● Inspect the load handling attachments on the machine for possible damage. Replace any
load handling attachments that are found to be damaged.
● Check before use that the load handling attachments are correctly secured.
● When lifting the machine, use only approved and undamaged lifting gear of sufficient rated
capacity. Check these before using them.
WARNING
The machine can be dropped
If the load handling attachments and lifting gear are damaged or not correctly secured,
the machine may be dropped during lifting. This can result in death, serious injury or
material damage. Inspect the load handling attachments and lifting gear before use.
Mounting
5.2 Lift the machine to where it will be mounted and position it
SIMOTICS M-1PH8 1PH818., 1PH822.
Operating Instructions 07/2016 53
