Machine design
The regulations and standards used as basis for designing and testing this machine are
stamped on the rating plate. The machine design basically complies with the subsequent
standards: Please refer to the EC or EU Declaration of Conformity for the versions of the
harmonized standards referenced.
Table 3-2 Machine design
Feature Standard
Dimensions and operation characteristics IEC / EN 60034-1
Degree of protection IEC / EN 60034-5
Cooling IEC / EN 60034-6
Type of construction IEC / EN 60034-7
Terminal markings and direction of rotation IEC/EN 60034-8
Noise emission IEC / EN 60034-9
Mechanical vibrations IEC / EN 60034-14
IEC‑standard voltages IEC/DIN IEC 60038
Vibration limit values DIN ISO 10816-3
Relevant directives
The following directives are relevant for the SIMOTICS motor series.
European low-voltage directive
The SIMOTICS motor series complies with the requirements of the low-voltage directive
2014/35/EU.
European machinery directive
The SIMOTICS motor series does not fall within the area of validity of the machinery directive.
However, the use of the products in a typical machine application has been fully assessed for
compliance with the main regulations in this directive concerning health and safety.
European EMC Directive
The SIMOTICS motor series does not fall within the area of validity of the EMC directive. The
products are not considered as devices in the sense of the directive.
Eurasian conformity
The SIMOTICS motor series complies with the requirements of the Russia/Belarus/
Kazakhstan customs union (EAC).
China Compulsory Certification
The SIMOTICS motor series does not fall in the area of validity of the China Compulsory
Certification (CCC).
Description
SIMOTICS M-1PH8 1PH818., 1PH822.
Operating Instructions 07/2016 23
