Operator control (hardware)
3.1 Operator control and display elements
3.1.2 Nameplates
Lateral nameplate
The following figure shows you all the information included in the nameplate located on the
side of the unit.
0RGXOHGHVLJQDWLRQ
2UGHUQXPEHU
6HULDOQXPEHU
+:UHOHDVH
Figure 3-2 Nameplate
You might need to access the information provided on the side-mounted nameplate after the
D4xx has been mounted. The nameplate is located on the right-hand side of the module
housing, which is the side typically used to connect to the SINAMICS S120 module; for this
reason, we recommend that you make a note of the serial number of the control unit prior to
assembly.
Note
The information contained in each field of the nameplate on your actual control unit may
differ from the information presented in this manual (for example, a higher product version,
approvals and marks that have not yet been earned, etc., may be shown).
D4xx
Manual, 12.2004, 6AU1900-1AJ32-0BA0
3-5
