7.3 Terminal board TB30
7.3 Terminal board TB30
Features of the TB30
The TB30 is a terminal expansion module that can be inserted in the D4xx.
The TB30 contains the following terminals:
Table 7-1 Overview of TB30 interface
Interface Number
Digital inputs 4
Digital outputs 4
Analog inputs 2
Analog outputs 2
Additional references
You can find additional information about the TB30 option board in the SINAMICS S120
product manual and the SINAMICS S120 commissioning manual.
Caution
The Option Board may only be inserted and removed when the D4xx Control Unit and the
TB30 Option Board are deenergized.
7.4 Terminal module TM31
Features of the TM31
With the terminal module TM31, the number of available digital inputs and outputs and the
number of analog input and outputs within a drive can be expanded The TM31 can be
connected by means of DRIVE CLiQ. It has 2 DRIVE CLiQ interfaces for this purpose.
The TM31 contains the following terminals:
Table 7-2 Interface overview of the TM31
Interface Number
Digital inputs 8
Bidirectional inputs/outputs 4
Relay outputs with changeover contact 2
D4xx
Manual, 12.2004, 6AU1900-1AJ32-0BA0
7-5
