Technical Data
5
5.1 Technical data for D435 and D425
Technical Data
The following technical data are relevant for the D435 and D425.
Additional references
For information on system clocks and address ranges of the SIMOTION D435 and
SIMOTION D425, refer to the SIMOTION SCOUT configuration manual.
Memory for user data
Table 5-1 Memories for user data and their memory size
Data Memory size
Diagnostics buffer 100 messages
Connection values
Table 5-2 Electrical connection values
parameters Value range
Supply voltage VDC (permissible range: 20,4 ... 28.8 V)
Power consumption from 24 V Typical power consumption: 0.6 A (inputs/outputs
are open; power is not being supplied to DRIVE
CLiQ I/O)
Power loss 15 W
Starting current 6 A
Dimensions and weight
Table 5-3 Dimension and weight of D435 and D425
parameters Values
Dimensions W x H x D [mm]
D4xx
Manual, 12.2004, 6AU1900-1AJ32-0BA0
5-1
