Spare parts/accessories
7.6 Terminal modules TM15 and TM17 High Feature
7.6 Terminal modules TM15 and TM17 High Feature
Features of TM15 and TM17 High Feature
The terminal modules TM15 and TM17 High Feature are used to implement measuring
inputs and cam outputs for SIMOTION D. In addition, these terminal modules provide drive-
related digital inputs and outputs with short signal delay times.
TM15
Each of the 24 isolated DI/O can be parameterized channel-by-channel as a digital input
(DI), digital output (DO), measuring input, or output of the output cam.
TM17 High Feature
Each of the 16 DI/O can be parameterized channel-by-channel as a digital input (DI), digital
output (DO), measuring input, or output of the output cam.
As compared to TM15, TM17 High Feature has fewer I/O channels–but with higher
functionality. TM17 High Feature is characterized, in particular, by an extremely high
resolution and accuracy, as well as an input filter–that can be parameterized–and enable
inputs (up to 6). Parameterized enable inputs can enable measuring inputs or outputs of
output cams (gate function). Due to their high accuracy, the DI/O channels of the TM17 High
Feature are non-isolated.
Additional references
You can find more information about TM15 and TM17 High Feature in the operator's guide
for SINAMICS TM15 and TM17 High Feature.
Caution
The 50 mm clearances above and below the components must be observed.
D4xx
Manual, 12.2004, 6AU1900-1AJ32-0BA0
7-7
