Interfaces
4.5 Power supply
The enables for the drive units and/or motors (active line module, motor module) connected
to the control unit can be switched using the digital inputs.
Electrically isolated inputs
The control unit has 8 digital inputs.
The isolated inputs can be used as freely addressable inputs.
Bidirectional inputs/outputs
The control unit has 8 digital inputs/outputs.
Six of the eight digital inputs/outputs can be used as "fast inputs." All eight digital
inputs/outputs can be used as freely addressable inputs or homing inputs. When
parameterized as digital outputs, the digital input/outputs can be used as freely addressable
outputs.
4.5 Power supply
4.5.1 Power supply X124
Features of the interface
Table 4-11 Interface X124
Features Type
Connector type Combicon
Connection possibility: up to 2.5 mm
2
Current carrying capacity 10 A, maximum
Maximum cable length 10 m
Interface assignments
Table 4-12 Power supply X124
Pin Signal name Signal type Meaning
1 P24 VI Power supply 24 V
2 P24 VI
3 M VO
4 M VO Ground
Signal type: VI = Voltage input (power supply) VO = Voltage output (power supply)
D4xx
Manual, 12.2004, 6AU1900-1AJ32-0BA0
4-11
