Interfaces
4.4 Digital inputs/outputs
X132 Digital inputs/outputs
Pin Signal name Signal type Meaning
1 DI4 I Digital input 4
2 DI5 I Digital input 5
3 DI6 I Digital input 6
4 DI7 I Digital input 7
5 M2 GND Ground for DI4 – DI7
(functionally-separated
relative to M)
6 M GND Ground
7 DI/DO12 B Digital input/output 12
8 DI/DO13 B Digital input/output 13 (fast
input)
9 M GND Ground
10 DI/DO14 B Digital input/output 14 (fast
input)
11 DI/DO15 B Digital input/output 15 (fast
input)
12 M GND Ground
4.4.3 Technical data for X122 and X132
Digital inputs on X122/X132
Table 4-9 Technical data of digital inputs X122/X132
parameters Values
Voltage -3 V to 30 V
Typical power consumption 10 mA at 24 VDC
Electrically isolated Reference potential is terminal M1 or M2
Signal level (including ripple factor) High signal level: 15 V to 30 V
Low signal level: -3 V to 5 V
Signal propagation delays L ∀ H: 50 μs
H ∀ L: 100 μs
D4xx
Manual, 12.2004, 6AU1900-1AJ32-0BA0
4-9
